Volumetric Flow Meter Types: All You Need to Know

Volumetric flow meters are essential instruments in industries that rely on precise measurement of fluid volume, including oil & gas, chemical processing, and fuel distribution. However, not all flow meters operate in the same way. Some technologies, like Positive Displacement (PD) meters, measure volume as a primary parameter, ensuring maximum accuracy. Others, such as turbine, vortex, and ultrasonic flow meters, assess different properties —such as velocity or mass— and derive volumetric measure from those measurements.



Understanding the distinction between direct volumetric measurement and inferred volumetric flow is crucial when selecting the right flow meter for industrial applications, especially where regulatory compliance or financial transactions depend on accurate volume readings.

If you need a technical support, don’t hesitate to contact our experts

Contact us for a free consultation!







Positive Displacement (PD) Volumetric Flow Meters type: The Gold Standard in Volumetric Measurement

Among the various types of flow meters, PD meters stand out as the only technology that measures volume directly. These meters work by trapping a fixed volume of fluid and counting how many times that volume is displaced within a given period. This makes them one of the most accurate and reliable options for industries where even slight measurement discrepancies can have significant consequences.



PD flow meters are widely used in applications that require precise billing and custody transfer, including fuel sales, chemical dosing. They are particularly common in the petroleum industry, where they ensure accurate metering of gasoline, diesel, jet fuel, and other hydrocarbons.

PD Volumetric Flow Meters Types



Aviation PD Meters



Aviation fuel requires the highest levels of accuracy due to strict industry regulations and safety standards. PD meters ensure that jet fuel and aviation gasoline are dispensed with precise volume control, preventing discrepancies in fueling operations.



Stainless Steel volumetric PD Meters (2’’ – 6’’)

These meters are built for durability and resistance to corrosive fluids. They are commonly used in the chemical and pharmaceutical industries, where aggressive liquids require specialized materials to ensure long-term reliability.



Single Case volumetric PD Meters (1 ½’’ – 8’’)

Designed for stable pressure environments, single-case PD meters are widely used in refineries, industrial liquid transfer, and fuel dispensing stations. They provide excellent accuracy in controlled conditions.



Double Case volumetric PD Meters (3’’ – 10’’)

For environments with high pressure values, double-case PD meters offer superior performance by compensating for changes in operating conditions. This makes them ideal for pipeline transportation and high-volume industrial applications.



Volumetric Gravity Meters (3’’ – 4’’)

These meters operate without additional pumping, relying entirely on gravitational force. They are commonly found in fuel road transportation where flow is dictated by gravity.



Pump & Gravity Meters (3’’ – 4’’)

A hybrid solution that works in both pumped and gravity-fed systems, these meters are highly versatile. They are frequently used in fuel road transportation where multiple flow conditions exist, typically gravity deliveries (gas stations) and pump deliveries (private utilities).



Key Advantages of PD Volumetric Flow Meters:



• Exceptional Accuracy – Unaffected by fluid velocity, ensuring consistent measurement.
• Versatility – Works with high-viscosity and low-viscosity fluids alike.
• Repeatability – Delivers precise and consistent results over time.



PD meters are the preferred choice for applications where the measurement of volume itself is critical, rather than just an estimate derived from other parameters.





Other Flow Meter Types: Measuring Indirect Parameters to Infer Volume

While PD volumetric flow meters types provide a direct measurement of volume, other technologies measure different properties— such as velocity, differential pressure, or mass — and use those readings to calculate volumetric flow. These technologies are useful in many industrial settings but do not measure volume as a primary quantity.

Turbine Flow Meters

Turbine meters determine flow rate by measuring the speed of a rotating turbine blade in the fluid stream. They are most effective for clean, low-viscosity liquids and gases such as water, LPG, and natural gas. However, they require stable flow conditions for accurate measurement.





Vortex Flow Meters

Vortex meters function by detecting vortices created by an obstruction in the flow path. The frequency of these vortices correlates with fluid velocity, allowing an estimate of volumetric flow. They are often used for steam, air, and process gas applications.





Electromagnetic (Magnetic) Flow Meters

Electromagnetic meters measure fluid velocity using Faraday’s Law of electromagnetic induction. They are ideal for conductive liquids such as water, wastewater, and certain chemical solutions, but they cannot measure hydrocarbons like gasoline or jet fuel.





Ultrasonic Flow Meters (Transit-Time Type)

Ultrasonic flow meters use sound waves to determine the velocity of a fluid and infer volumetric flow. Since they are non-intrusive, they are widely used in applications where the fluid should not be disturbed, such as in pharmaceutical manufacturing and food production.





Choosing the Right Flow Meter type for Your Application

When selecting a flow meter, it is crucial to consider whether the measurement must be in volume or if a derived volumetric calculation is acceptable.



PD volumetric flow meters types are the preferred choice when legal, financial, or regulatory compliance requires a direct volume measurement. Industries where billing and custody transfer depend on volume accuracy—such as gasoline, diesel, jet fuel, and other fuel sales—rely heavily on PD meters to ensure transparency and precision.



On the other hand, industries that require flow monitoring rather than precise volume measurement, such as water treatment, HVAC, and compressed air systems, may benefit from alternative technologies like electromagnetic, vortex, or ultrasonic flow meters.



Choosing the right flow meter ensures operational efficiency, compliance with industry regulations, and accurate financial transactions. If you need technical guidance in selecting the best flow measurement solution for your application, don’t hesitate to contact our specialists.
